ELEVATING STANDARDS IN VERTICAL MOBILITY
Hospital Bed Elevator
Prioritize care and precision with our advanced hospital bed elevators, where life-saving speed meets unparalleled stability. Engineered for the most sensitive medical environments, our lifts offer extra-wide clearances and whisper-smooth transitions, ensuring a safe, serene, and ultra-reliable journey for patients and healthcare heroes alike.
Get A Quotation
Cabin Details
GEC-B01
- Ceiling: Hairline stairless Steel LED energy saving light
- Ventilation: Axial fan
- Car wall: Hairline stainless steel
- Handrail: Double flat stainless steel
- Front: PVC Floorboard
Cabin Details
GEC-B02
- Ceiling: Painted Steel plate, LED energy saving light
- Ventilation: Axial fan
- Car wall: Hairline stainless steel
- Handrail: Stainless steel Tube
- Front: PVC Floorboard
Cabin Details
GEC-B04
- Ceiling: GEC-J117 steel plate coating +LED downlight
- Rear wall: Hairline stainless steel
- Side wall: Hairline stainless steel
- Floor: GEC-DB207 PVC
- Car door: Hairline stainless steel
- Front Wall: Hairline stainless steel
- Handrail: GEC-FS03 hairline stainless steel
Cabin Details
GEC-B05
- Ceiling: GEC-J226 Aluminum alloy frame + middle hairline stainless steel + acrylic +LED light
- Rear wall: Hairline stainless steel
- Side wall: Hairline stainless steel
- Floor: GEC-DB207 PVC
- Car door: Hairline stainless steel
- Front Wall: Hairline stainless steel
- Handrail: GEC-FS03 hairline stainless steel
Cabin Details
GEC-01
- Ceiling: GEC-C028 M002 baking varnish elegant gold Acrylic light transmission plate +led light
- Cabin: Apple sand bronze gold
- Wall: Mirror platinum Mirror platinum+etchingP031
- Floor: F024，Single color PVC
Cabin Details
GEC-06
- Ceiling: CO-037 Middle apple sand stainless steel LED light strip hidden in milky acrylic board around
- Cabin Wall: Apple sand + anti fingerprint Mirror stainless steel + anti fingerprint Matte white sprayed steel plate
- Floor: F020, black and white
Technical Perimeter For Hospital Bed Elevator
| Model | Load KG |
Passngr NO. |
Speed m/s |
Car Spec. CWxCD |
Door Opening JJxOPH |
Well Size HWxHD |
Machine Room MRWxMRD |
Pit Depth Pit |
Top Height OH |
Power | Acting Force | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| R1 | R2 | R3 | P1 | P2 | |||||||||||
| GEC1600/1.0 | 1600 | 21 | 1.0 | 1400x2400 | 1100x2100 | 2500x2950 | 2500x2950 | 1400 | 4500 | 11 | 73600 | 47600 | 9600 | 128000 | 96000 |
| GEC1600/1.5 | 1.5 | 1500 | 4600 | 16.6 | |||||||||||
| GEC1600/1.75 | 1.75 | 1600 | 4700 | 19.4 | |||||||||||
| GEC1800/1.0 | 1800 | 24 | 1.0 | 1600x2400 | 1200x2100 | 2750x2900 | 2750x2900 | 1500 | 4500 | 16 | 73600 | 47600 | 9600 | 128000 | 96000 |
| GEC1800/1.5 | 1.5 | 1600 | 4700 | 22 | |||||||||||
| GEC1800/1.75 | 1.75 | 1800 | 4900 | 22 | |||||||||||
| GEC2000/1.0 | 2000 | 26 | 1.0 | 1700x2400 | 1200x2100 | 2850x2900 | 2850x2900 | 1500 | 4500 | 17 | 73600 | 47600 | 9600 | 128000 | 96000 |
| GEC2000/1.5 | 1.5 | 1600 | 4700 | 22 | |||||||||||
| GEC2000/1.75 | 1.75 | 1800 | 4900 | 30 | |||||||||||
Hospital Bed Elevator Customization Options
- 1. Precision Drive Systems: Choose between high-precision geared or advanced gearless traction machines for ultra-smooth starts and stops, ensuring zero discomfort for sensitive patients.
- 2. Product Configurations: Available in medical-grade semi-imported, fully imported, or globally branded configurations to meet the rigorous demands of healthcare facilities.
- 3. Clinical Cabin Designs: Customize with antibacterial stainless steel walls, recessed LED lighting, and shock-absorbent bumper rails to protect against stretcher and bed impacts.
- 4. Specialized Door Systems: Select from extra-wide center-opening or side-opening automatic doors with extended "door-open" timers for safe and easy patient transfer.
- 5. Advanced Emergency Features: Equipped with a high-capacity Emergency Rescue Device (ERD) and "Attendant Service" mode to give medical staff priority control during emergencies.
- 6. Flexible Installation Layouts: Available in deep-cabin Machine Room (MR) or space-saving Machine Room-Less (MRL) configurations to maximize hospital floor planning.
Please Note:
- Stretcher Standards: According to medical building codes, cabin dimensions are specifically extended to accommodate standard hospital beds (typically 2400mm deep) and medical personnel.
- Power Efficiency (Geared): For geared hospital lifts at 60–100 m/min, power consumption is 1.1 kW per 100 kg of rated capacity to handle high-frequency usage.
- Power Efficiency (Gearless): For gearless hospital lifts at 60–100 m/min, power consumption is 0.7 kW per 100 kg of rated capacity, offering quieter operation for recovery zones.
- Electrical Power Requirements: 380–440V, 3-Phase, 50Hz.
